Stainless steel branches 45°
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Product video
Article no.
Ø [mm]
WS [mm]
L1 [mm]
L2 [mm]
A45E-038015-038015
38,0
1,5
250
160
A45E-040015-040015
40,0
1,5
250
160
A45E-045015-045015
45,0
1,5
250
160
A45E-050015-050015
50,0
1,5
250
160
A45E-050020-050020
50,0
2,0
250
160
A45E-054020-054020
54,0
2,0
250
160
A45E-060315-060315
60,3
1,5
280
180
A45E-060320-060320
60,3
2,0
280
180
A45E-065020-065020
65,0
2,0
280
180
A45E-070020-070020
70,0
2,0
280
180
A45E-076020-076020
76,1
2,0
350
230
A45E-080020-080020
80,0
2,0
350
230
A45E-084020-084020
84,0
2,0
350
230
A45E-088920-088920
88,9
2,0
350
230
A45E-101620-101620
101,6
2,0
430
300
A45E-104020-104020
104,0
2,0
430
230
A45E-108020-108020
108,0
2,0
430
300
A45E-114320-114320
114,3
2,0
430
300
Stainless steel branches 45° | small outlet
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L1 [mm]
L3 [mm]
A45E-060315-040015
60,3
1,5
40,0
1,5
280
180
A45E-060315-045015
60,3
1,5
45,0
1,5
280
180
A45E-060315-050015
60,3
1,5
50,0
1,5
280
180
A45E-076120-050015
76,1
2,0
50,0
1,5
350
230
A45E-076120-060320
76,1
2,0
60,3
1,5
350
230
Stainless steel branches 30°
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Article no.
Ø [mm]
WS [mm]
L1 [mm]
L2 [mm]
A30E-038015-038015
38,0
1,5
300
205
A30E-040015-040015
40,0
1,5
300
205
A30E-045015-045015
45,0
1,5
300
205
A30E-050015-050015
50,0
1,5
300
205
A30E-054020-054020
54,0
2,0
300
205
A30E-060315-060315
60,3
1,5
400
300
A30E-065020-065020
65,0
2,0
400
300
A30E-070020-070020
70,0
2,0
400
300
A30E-076120-076120
76,1
2,0
450
345
A30E-080020-080020
80,0
2,0
450
345
A30E-084020-084020
84,0
2,0
500
390
A30E-088920-088920
88,9
2,0
500
390
Stainless steel T-piece
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Article no.
Ø1 [mm]
WS1 [mm]
L1 [mm]
L2 [mm]
TSE-038015-038015-250
38,0
1,5
250
125
TSE-040015-040015-250
40,0
1,5
250
125
TSE-045015-045015-250
45,0
1,5
250
125
TSE-050015-050015-250
50,0
1,5
250
125
TSE-050020-050020-250
50,0
2,0
250
125
TSE-054020-054020-250
54,0
2,0
250
125
TSE-060315-060315-250
60,3
1,5
250
125
TSE-060320-060320-250
60,3
2,0
250
125
TSE-065020-065020-280
65,0
50
280
140
TSE-070020-070020-280
70,0
2,0
280
140
TSE-076120-076120-280
76,1
2,0
280
140
TSE-080020-080020-280
80,0
2,0
280
140
TSE-084020-084020-320
84,0
2,0
320
160
TSE-088920-088920-320
88,9
2,0
320
160
TSE-101620-101620-320
101,6
2,0
320
160
TSE-104020-104020-320
104,0
2,0
320
160
TSE-108020-108020-320
108,0
2,0
320
160
TSE-114320-114320-320
114,3
2,0
320
160
Stainless steel T-piece | small outlet
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L1 [mm]
L2 [mm]
TSE-050015-040015-250
50,0
1,5
40,0
1,5
250
125
TSE-060315-045015-250
60,3
1,5
45,0
1,5
250
125
TSE-060315-050015-250
60,3
1,5
50,0
1,5
250
125
TSE-076120-050015-280
76,1
2,0
50,0
1,5
280
140
TSE-076120-060315-280
76,1
2,0
60,3
1,5
280
140
Stainless steel T-piece closed on one side
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Article no.
Ø1 [mm]
WS1 [mm]
L1 [mm]
L2 [mm]
TSGG-040015-040015
40,0
1,5
180
125
TSGG-045015-045015
45,0
1,5
185
130
TSGG-050015-050015
50,0
1,5
185
130
TSGG-060315-060315
60,3
1,5
190
135
TSGG-076120-076120
76,1
2,0
230
160
Stainless steel Y-piece
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Article no.
Ø1 [mm]
WS1 [mm]
L1 [mm]
L2 [mm]
YSE-038015-038015-120
38,0
1,5
120
120
YSE-040015-040015-120
40,0
1,5
120
120
YSE-045015-045015-120
45,0
1,5
120
120
YSE-050015-050015-120
50,0
1,5
120
120
YSE-054020-054020-120
54,0
2,0
120
120
YSE-060315-060315-140
60,3
1,5
140
140
YSE-065020-065020-140
65,0
2,0
140
140
YSE-070020-070020-140
70,0
2,0
140
140
YSE-076120-076120-160
76,1
2,0
160
160
YSE-080020-080020-160
80,0
2,0
160
160
YSE-084020-084020-160
84,0
2,0
160
160
YSE-088920-088920-180
88,9
2,0
180
180
Stainless steel L-piece
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Article no.
Ø1 [mm]
WS1 [mm]
Axial dimension [mm]
L1 [mm]
L2 [mm]
LSE-040015-0130-0130
40,0
1,5
130
150
150
LSE-045015-0128-0128
40,0
1,5
128
150
150
LSE-050015-0125-0125
50,0
1,5
125
150
150
LSE-060315-0120-0120
60,3
1,5
120
150
150
LSE-076120-0162-0162
76,1
2,0
162
200
200
Stainless steel | reduction
Facts
Material: Stainless steel 1.4301
Cleaned and deburred
Smoothed inside seam
Product video
Ø40.0 X 1.5 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-040015-038015-120
40,0
1,5
38,0
1,5
approx. 120
Ø45.0 X 1.5 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-045015-038015-120
45,0
1,5
38,0
1,5
approx. 120
RSE-045015-040015-120
45,0
1,5
40,0
1,5
approx. 120
Ø50.0 X 1.5 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-050015-038015-120
50,0
1,5
38,0
50
approx. 120
RSE-050015-040015-120
50,0
1,5
40,0
1,5
approx. 120
RSE-050015-045015-120
50,0
1,5
45,0
1,5
approx. 120
Ø54.0 X 1.5 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-054015-038015-120
54,0
1,5
38,0
1,5
approx. 120
RSE-054015-040015-120
54,0
1,5
40,0
1,5
approx. 120
RSE-054015-045015-120
54,0
1,5
45,0
1,5
approx. 120
RSE-054015-050015-150
54,0
1,5
50,0
1,5
approx. 150
Ø60.3 X 1.5 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-060315-040015-130
60,3
1,5
40,0
1,5
approx. 130
RSE-060315-045015-120
60,3
1,5
45,0
1,5
approx. 120
RSE-060315-050015-120
60,3
1,5
50,0
1,5
approx. 120
RSE-060315-054020-150
60,3
1,5
54,0
2,0
approx. 150
Ø65.0 X 1.5 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-065020-045015-140
65,0
2,0
45,0
1,5
approx. 140
RSE-065020-050015-150
65,0
2,0
50,0
1,5
approx. 150
RSE-065020-054020-150
65,0
2,0
54,0
2,0
approx. 150
RSE-065020-060315-150
65,0
2,0
60,3
1,5
approx. 150
RSE-065020-060320-150
65,0
2,0
60,3
2,0
approx. 150
Ø70.0 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-070020-050015-200
70,0
2,0
50,0
1,5
approx. 200
RSE-070020-054020-200
70,0
2,0
54,0
2,0
approx. 200
RSE-070020-060315-200
70,0
2,0
60,3
1,5
approx. 200
RSE-070020-060320-200
70,0
2,0
60,3
2,0
approx. 200
RSE-070020-065020-200
70,0
2,0
65,0
2,0
approx. 200
Ø76.1 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-076120-060315-200
76,1
2,0
60,3
1,5
approx. 200
RSE-076120-060320-200
76,1
2,0
60,3
2,0
approx. 200
RSE-076120-065020-200
76,1
2,0
65,0
2,0
approx. 200
RSE-076120-070020-200
76,1
2,0
70,0
2,0
approx. 200
Ø80.0 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-080020-060315-200
80,0
2,0
60,3
1,5
approx. 200
RSE-080020-060320-200
80,0
2,0
60,3
2,0
approx. 200
RSE-080020-065015-200
80,0
2,0
65,0
1,5
approx. 200
RSE-080020-070020-200
80,0
2,0
70,0
2,0
approx. 200
RSE-080020-076120-200
80,0
2,0
76,1
2,0
approx. 200
Ø84.0 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-084020-065020-200
84,0
2,0
65,0
2,0
approx. 200
RSE-084020-070020-200
84,0
2,0
70,0
2,0
approx. 200
RSE-084020-076120-200
84,0
2,0
76,1
2,0
approx. 200
RSE-084020-080020-200
84,0
2,0
80,0
2,0
approx. 200
Ø88.9 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-088920-070020-200
88,9
2,0
70,0
2,0
approx. 200
RSE-088920-076120-200
88,9
2,0
76,1
2,0
approx. 200
RSE-088920-080020-200
88,9
2,0
80,0
2,0
approx. 200
RSE-088920-084020-200
88,9
2,0
84,0
2,0
approx. 200
Ø101.6 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-101620-076120-200
101,6
2,0
76,1
2,0
approx. 200
RSE-101620-080020-200
101,6
2,0
80,0
2,0
approx. 200
RSE-101620-084020-200
101,6
2,0
84,0
2,0
approx. 200
RSE-101620-088920-200
101,6
2,0
88,9
2,0
approx. 200
Ø104 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-104020-084020-200
104,0
2,0
84,0
2,0
approx. 200
RSE-104020-088920-200
104,0
2,0
88,9
2,0
approx. 200
RSE-104020-101620-200
104,0
2,0
101,6
2,0
approx. 200
Ø108 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-108020-088920-200
108,0
2,0
88,9
2,0
approx. 200
RSE-108020-101620-200
108,0
2,0
101,6
2,0
approx. 200
RSE-108020-104020-200
108,0
2,0
104,0
2,0
approx. 200
Ø114.3 X 2.0 mm
Article no.
Ø1 [mm]
WS1 [mm]
Ø2 [mm]
WS2 [mm]
L [mm]
RSE-114320-101620-200
114,3
2,0
101,6
2,0
approx. 200
RSE-114320-104020-200
114,3
2,0
104,0
2,0
approx. 200
RSE-114320-108020-200
114,3
2,0
108,0
2,0
approx. 200
PRODUCT DESCRIPTION
At Michel Tube, stainless steel tube fittings are cut on tube laser systems and predominantly laser-welded. Laser welding enables filigree components and ensures extremely low distortion and burn-through inside the conveyor tube.
All plastic industry tube fittings are supplied ready for installation in manageable batch sizes and are available from stock.
PICTURE GALLERY
Standard tube connector for glass and stainless steel
For connecting glass and stainless steel tubes
Stainless steel round tube
material: stainless steel 1.4301
Length: 6000mm
Smoothed inside seam
Technical data
Material:
Stainless steel 1.4301
Standard length:
6000mm
Diameter:
38 - 168.3mm
Wall thickness:
1.5mm, 2mm & 3mm
Item numbers
Outside Ø
Radius 100 / 120 / 150 mm
Radius 250 mm
Radius 500 mm
Radius 800 mm
38.0 x 1.5
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1234
40.0 x 1.5
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
45.0 x 1.5
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
50.0 x 1.5
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
50.0 x 2.0
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
RBE-038015-90100-1010
50.0 x 1.5
RBE-038015-90100-1010
50.0 x 1.5
RBE-038015-90100-1010
50.0 x 1.5
RBE-038015-90100-1010
50.0 x 1.5
RBE-038015-90100-1010
